Host BUS Interface Continue
Name Pin Attr Signal Description
HPCOMP
I
M
GTL P-MOS Compensation Input
HVREF[4:0]
HNCOMPVREF
I
M
AGTL+ I/O reference voltage
DRAM Controller
Name Pin Attr Signal Description
SDCLK
I
3.3V - M
SDRAM Clock Input
SDRCLKI
I
2.5V/3.3V - M
SDRAM Read Clock Input
FWDSDCLKO
O
2.5V/3.3V – M
SDRAM Forward Clock Output
MA[14:0]
O
2.5V/3.3V - M
System Memory Address Bus
SRAS#
O
2.5V/3.3V - M
SDRAM Row Address Strobe
SCAS#
O
2.5V/3.3V - M
SDRAM Column Address Strobe
SWE#
O
2.5V/3.3V - M
SDRAM Write Enable
CS[5:0]#
CSB[5:0]#
O
2.5V/3.3V - M
SDRAM Chip Select
CSB[5:0] multiplexed with DQS[5:0]
DQM[7:0]#
O
2.5V/3.3V - M
SDRAM Input/Output Data Mask
DQS[7:0]
I/O
2.5V/3.3V - M
DDR Data Strobe
MD[63:0]
I/O
2.5V/3.3V - M
System Memory Data Bus
CKE[5:0]
O (open-drain)
2.5V/3.3V –
AUX
SDRAM Clock Enable
S3AUXSW#
(CKE6)
O (open-drain)
2.5V/3.3V -
AUX
Aux power switch for ACPI-S3 state, low active.
DDRVREF[A:B]
I
M
DDR I/O Reference Voltage
SiS MuTIOL Interface
Name Pin Attr Signal Description
ZCLK
I
3.3V - M
SiS MuTIOL Connect
ZUREQ/ZD
REQ
I/O
1.8V - M
SiS MuTIOL Connect Control pins
ZSTB[1:0]
I/O
1.8V - M
SiS MuTIOL Connect Strobe
ZSTB[1:0]#
I/O
1.8V - M
Strobe Compliment
ZAD[15:0]
I/O
1.8V - M
I/O
1.8V - M
ZVREF
I
M
SiS MuTIOL Connect Reference Voltage
ZCMP_N
I
M
N-MOS Compensation Input
ZCMP_P
I
M
P-MOS Compensation Input
SiS MuTIOL Interface Continue
Name Pin Attr Signal Description
AGPCLK
I
3.3V – M
AGP Clock
AFRAME#
I/O
1.5V/3.3V - M
AGP Frame#
AIRDY#
I/O
1.5V/3.3V - M
AGP Initiator Ready
ATRDY#
I/O
1.5V/3.3V - M
AGP Target Ready
ASTOP#
I/O
1.5V/3.3V - M
AGP Stop#
ADEVSEL#
I/O
1.5V/3.3V - M
AGP Device Select
ASERR#
I
1.5V/3.3V - M
AGP System Error
AREQ#
I
1.5V/3.3V - M
AGP Bus Request
AGNT#
O
1.5V/3.3V - M
AGP Bus Grant
AAD[31:0]
I/O
1.5V/3.3V - M
AGP Address/Data Bus
5.2 SiS650 IGUI Host/Memory Controller
