N/B Maintenance
N/B Maintenance
Part Number Description Location(s)
271071604811 RES;60.4 ,1/16W,1% ,0603,SMT R50
271071619811 RES;61.9 ,1/16W,1% ,0603,SMT R27,R30
271071620102 RES;62,1/16W,1% 0603,SMT R10,R11,R528
271071681101 RES;680 ,1/16W,1% ,0603,SMT R534
271071750101 RES;75 ,1/16W,1% ,0603,SMT R25,R562
271071750302 RES;75 ,1/16W,5% ,0603,SMT R31,R35,R525,R537,R538,R5
271071822301 RES;8.2K ,1/16W,5% ,0603,SMT R190
271071806211 RES;80.6K,1/16W,1% ,0603,SMT PR518
271071820301 RES;82 ,1/16W,5% ,0603,SMT R205,R207,R210,R777
271071909101 RES;9.09K,1/16W,1% ,0603,SMT R228
271071976311 RES;976K ,1/16W,1% ,0603,SMT PR8
271611000301 RP;0*4 ,8P ,1/16W,5% ,0612,SMT RP1,RP2,RP3,RP4
271611000301 RP;0*4 ,8P ,1/16W,5% ,0612,SMT RP48,RP501,RP503,RP504,R
P
271571000301 RP;0*8 ,16P ,1/16W,5% ,1606,SM RP13,RP14,RP15
271611100301 RP;10*4 ,8P ,1/16W,5% ,0612,SMT FA502,FA503,FA504,FA505,
F
271571100301 RP;10*8 ,16P ,1/16W,5% ,1606,SM RP10,RP11,RP12,RP16,RP17
271611103301 RP;10K*4 ,8P ,1/16W,5% ,0612,SMT RP3,RP4,RP40,RP518,RP529
271611102301 RP;1K*4 ,8P ,1/16W,5% ,0612,SMT RP1
271621102302 RP;1K*8 ,10P,1/32W,5% ,1206,SMT RP2,RP507
271611220301 RP;22*4 ,8P ,1/16W,5% ,0612,SMT RP5,RP512,RP6
271611330301 RP;33*4 ,8P ,1/16W,5% ,0612,SMT RP43,RP528
271571330301 RP;33*8 ,16P ,1/16W,5% ,1606,SM RP21,RP22,RP23,RP24,RP25
271611472301 RP;4.7K*4,8P ,1/16W,5% ,0612,SMT RP36,RP46,RP47,RP511,RP5
271621472303 RP;4.7K*8,10P,1/16W,5% ,1206,SMT RP514,RP519
271621471301 RP;470*4,8P,1/16W,5%,1206,SMT RP7
Part Number Description Location(s)
271621473301 RP;47K*8 ,10P,1/16W,5% ,1206,SMT RP513,RP517
271611750301 RP;75*4 ,8P ,1/16W,5% ,0612,SMT RP5
271611750301 RP;75*4 ,8P ,1/16W,5% ,0612,SMT RP502
271621822302 RP;8.2K*8,10P,1/32W,5% ,1206,SMT RP37,RP38,RP39
345671600002 RUBBER PAD;LCD,LOWER,8175
345671600001 RUBBER PAD;LCD,UPPER,8175
565167170001 S/W;CD ROM,SYSTEM DRIVER,8575
340671200013 SCREW ASSY;CPU,8170
340671200014 SCREW ASSY;IC,82845,8170
371102011502 SCREW;M2L15,FLT(+),NIW/NLK
340671700007 SHIELDING ASSY;TOP,8575
341671700001 SHIELDING;AUDIO,8575
370102610302 SPC-SCREW;M2.6L3,NIB,K-HD,NYLOK
370102610603 SPC-SCREW;M2.6L6,K-HD,NIB/NLK
370102610603 SPC-SCREW;M2.6L6,K-HD,NIB/NLK
370102030301 SPC-SCREW;M2L3,K-HD,1,NIB/NLK
370102030301 SPC-SCREW;M2L3,K-HD,1,NIB/NLK
370102030301 SPC-SCREW;M2L3,K-HD,1,NIB/NLK
370102030301 SPC-SCREW;M2L3,K-HD,1,NIB/NLK
370102010309 SPC-SCREW;M2L3.0,NIW/NLK,HD07
370102010407 SPC-SCREW;M2L4,K-HD,NIB/NLK
370102010407 SPC-SCREW;M2L4,K-HD,NIB/NLK
370102010606 SPC-SCREW;M2L6,K-HD(t0.2),NIB/NL
370103010405 SPC-SCREW;M3L4,NIW,K-HD,T0.3
370103010604 SPC-SCREW;M3L6,NIB,K-HD,t0.8,NYL
9. Spare Parts List - 20
