Part Number Description Location(s)
340671700003 SPEAKER ASSY,L,8575
340671700008 SPEAKER ASSY;R,8575
377244010002 STANDOFF;#4-40DP3.5H5L5.5,NIW
341668300008 STANDOFF;MDC MODEM,NLK,HOPE
297120101007 SW;DIP,SPST,4P,24VDC,.025A,SMT SW503
297040105012 SW;PUSH BUTTOM,4P,SP,12V/50MA,H2 SW502
297040105012 SW;PUSH BUTTOM,4P,SP,12V/50MA,H2 SW1,SW2,SW3,SW4,SW5,SW
6
297040105010 SW;PUSH BUTTOM,5P,SPST,12V/50MA, SW1,SW2,SW3,SW4
297030102001 SW;TOGGLE,SPST,5V/0.2mA,H10.7MM, SW1
225600000004 TAPE;DOUBLE SIDE,12MM*15M
345671700002 THERMAL PAD;MOS,8575
345671700003 THERMAL PAD;SIS301,8575
442164900010 TOUCH PAD MODULE;TM41PD-350
288227002001 TRANS;2N7002LT1,N-CHANNEL FET PQ2,PQ501,PQ502,PQ503
288227002001 TRANS;2N7002LT1,N-CHANNEL FET PQ4,PQ501,PQ502,PQ504,P
Q
288203401001 TRANS;AO3401,P-MOSFET,SOT-23 PQ1
288203401001 TRANS;AO3401,P-MOSFET,SOT-23 Q1,Q509,Q511,Q6,Q8
288200144002 TRANS;DTA144WK,PNP,SMT PQ506,Q529
288200144003 TRANS;DTC144TKA,N-MOSFET,SOT-23 Q10,Q11,Q17,Q18,Q19,Q2,Q
2
288200144001 TRANS;DTC144WK,NPN,SOT-23,SMT PQ509,Q20,Q5,Q510,Q9
288202222001 TRANS;MMBT2222AL,NPN,TO236AB PQ3
288203904010 TRANS;MMBT3904L,NPN,Tr35NS,TO236 Q15,Q516,Q517
288203906018 TRANS;MMBT3906L,PNP,Tr35NS,TO236 Q14
288207002001 TRANS;NDC7002N,N-MOSFET,SSOT-6 PQ2
288202302001 TRANS;SI2302DS,N-MOSFET,SOT-23 Q534
Part Number Description Location(s)
288204416001 TRANS;Si4416DY,N-MOSFET,.028OHM, PU2,PU5
288204416001 TRANS;Si4416DY,N-MOSFET,.028OHM, PU507,PU509
288204425002 TRANS;SI4425DY,PMOS,8.5A/30V,.02 PU502
288204425002 TRANS;SI4425DY,PMOS,8.5A/30V,.02 PU512,PU513
288204788001 TRANS;SI4788CY,P-MOS,5A1.8~5.5V, PU504,PU505
288204810001 TRANS;SI4810DY,N-MOS,.0155OHM,SO PU3,PU6
288204810001 TRANS;SI4810DY,N-MOS,.0155OHM,SO PU7,PU8
288204835001 TRANS;SI4835DY,PMOS,6A/30V,.035, PQ1
288204925001 TRANS;SI4925DY,P-MOSFET,SO-8 PU9
288209410001 TRANS;SI9410DY,N-MOSFET,.04OHM,S Q503
288205003004 TRANS;SUD50N03-11,N-MOS,TO252 PU1,PU2,PU4,PU5,PU501,P
U
273001050039 TRANSFORMER;10/100 BASE,LF-H80P, U3
271911103906 VR;10K,20%,0.05W,RN101GAC10KPGJ- VR1
421671700002 WIRE ASSY;ANTENNA,8575
421668300005 WIRE ASSY;BIOS,BATTERY,HOPE J508
421668300005 WIRE ASSY;BIOS,BATTERY,HOPE J508
421671600010 WIRE ASSY;INVERT,8175
421671700004 WIRE ASSY;MDC,EMI,8575
421671700001 WIRE ASSY;TOUCHPAD,8575
274011431408 XTAL;14.318M,50PPM,32PF,7*5,4P,S X502
274011431422 XTAL;14.318MHZ,16PF,20PPM,8*4.25 X501
274011600408 XTAL;16MHZ,16PF,50PPM,8*4.5,2P X503
274012457405 XTAL;24.576M,30PPM,16PF,7*5,4P,S X6
274012457406 XTAL;24.576MHZ,16PF,50PPM,8*4.5, X3
274012500401 XTAL;25MHZ,30PPM,18PF,4P,SMT X1,X4
