N/B Maintenance
N/B Maintenance
2.2.1 Battery Pack
Disassembly
1. Carefully put the notebook upside down.
2. Slide the release lever to the “unlock” ( ) position (), then sliding and holding the release lever
outwards while pull the battery pack out of the compartment (). (Figure 2-1)
Figure 2-1 Remove the battery pack
Reassembly
1. Push the battery pack into the compartment. The battery pack should be correctly connected when you
hear a clicking sound.
2. Slide the release lever to the “lock” ( ) position.
