78
8575
8575
N/B Maintenance
N/B Maintenance
2.2.2 Keyboard
Disassembly
1. Open the top cover.
2. Insert a small rod, such as a straightened paper clip, into the eject hole near the power connector of the
notebook. (Figure 2-2)
3. Push the rod firmly and slide the easy start buttons cover to the left (). Then lift the easy start buttons cover up
from the left side (). (Figure 2-3)
Figure 2-2 Insert a rod easy to remove Figure 2-16 Remove easy start
buttons cover


