Rear Panel
1. Power cord inlet: Plug in the supplied power cord here.
2. Digital Optical output. Connect an optical cable (not supplied) to connect to a digital input such as the optical input on the
Mitchell & Johnson SAP201V or SAP601 amplifiers.
3. RCA /phono stereo output connections. Connect supplied RCA to RCA stereo pair cable ensuring the red connector on the cable
is connected to the red connector on both the WLD+211 and your amplifier.
4. Ethernet cable connection for connecting an Ethernet network cable between the WLD+211 and a router.
5. 2.4 Ghz wi-fi antenna input jack (for internet radio) (supplied)
6. 75 ohm tuner antenna (supplied)
