RELEVANT DOCUMENTS
The relevant manuals are shown below. For the latest version of the manuals, check the MITSUBISHI ELECTRIC
FA website.
CR800 series controller
No.
Document
BFP-A3470
BFP-A3468
BFP-A3779
CR800 Controller RV-FR Series Standard Specifications Manual
CR800 Controller RH-FRH Series Standard Specifications Manual
CR860 Controller RV-35FR/50FR/80FR Series Standard Specifications Manual
BFP-A3478
CR800 Series Controller INSTRUCTION MANUAL Detailed explanations of functions
and operations
MELSEC iQ-R series
No.
Document
SH-081262ENG
MELSEC iQ-R Module Configuration Manual
SH-081263ENG
MELSEC iQ-R CPU Module User's Manual (Startup)
SH-081264ENG
MELSEC iQ-R CPU Module User's Manual (Application)
SH-082127ENG
MELSEC iQ-R CC-Link IE TSN User's Manual (Startup)
SH-082129ENG
MELSEC iQ-R CC-Link IE TSN User's Manual (Application)
SH-082227ENG
CC-Link IE TSN Remote I/O Module (With Safety Functions) User's Manual
SH-081538ENG
MELSEC iQ-R Safety Application Guide
BCN-P5999-0502
Mitsubishi Electric Safety Programmable Controller MELSEC iQ-R Series Machinery
Directive (2006/42/EC) Compliance
TERMS
This manual uses the following terms.
Term
Description
Safety programmable
controller
A MELSEC iQ-R series module that performs safety control: a
Safety CPU
module, a safety function module, a CC-Link IE TSN Network remote I/O
module (with safety functions).
Standard programmable
controller
A MELSEC iQ-R series module that performs standard control (This term is
used to distinguish such programmable controllers from the safety
programmable controllers.)
Safety CPU module
(RnSFCPU)
A module that performs both standard control and safety control and is used
with a safety function module.
Programmable controller
CPU module
Standard CPU module
(RnCPU)
A MELSEC iQ-R series CPU module that performs standard control (The term
ʺstandard CPU moduleʺ is used to distinguish from CPU modules that perform
safety control.)
Safety function module
(R6SFM)
A module that performs safety control and must be used with a Safety CPU
module. This module can only be used with the Safety CPU module.
Control CPU
A CPU module that controls connected I/O modules and intelligent function
modules.
Safety communications
Communication service that performs send/receive processing in the safety
layer of the safety communication protocol.
Standard communications
Communications other than safety communications, such as cyclic
transmission of CC-Link IE TSN Network.
Safety station
A station that performs safety communications and standard communications
in a safety system.
Station
A device connected to the network.
Host station, The other station (Communication Partner)
CC-Link IE TSN master/local
module
(RJ71GN11-T2)
A MELSEC iQ-R series network module that can be used as a master station
or a local station for CC-Link IE TSN.
The module is referred to as a master/local module in this manual.
Active
Safety connections are established from the own station.
Passive
Safety connections are established from the communication destination.
Safety connection
A connection established for safety communications.
