Mitsubishi Electric MELFA RV-3SDB Series User Manual

Operation of Teaching Box R32TB Menu tree
SD-/SQ series 6 - 3
R001541E
Fig. 6-1: Menu tree (3)
<SET/INITIALIZE>
1. INITIALIZE 2. POWER
3. CLOCK 4. VERSION
CLOSE
123
<ORIGIN> ABS
J1: ( 0 ) J2: ( 0 ) J3: ( 0 )
J4: ( 0 ) J5: ( 0 ) J6: ( 0 )
J7: ( 0 ) J8: ( 0 )
CLOSE
123
<ORIGIN> USER
J1: ( 0 ) J2: ( 0 ) J3: ( 0 )
J4: ( 0 ) J5: ( 0 ) J6: ( 0 )
J7: ( 0 ) J8: ( 0 )
CLOSE
123
<BRAKE>
J1: ( 0 ) J2: ( 0 ) J3: ( 0 )
J4: ( 0 ) J5: ( 0 ) J6: ( 0 )
J7: ( 0 ) J8: ( 0 )
CLOSE
123
REL.
<INITIALIZE>
1. DATA 2. PARAMETER
3. BATTERY
CLOSE
123
<HOURE DATA>
POWER ON TIME 18 Hr
BATTERY ACC. 14089 Hr
CLOSE
123
<CLOCK>
DATE 08-05-07
TIME 16:04:50
CLOSE
123
<VERSION>
R/C Ver. P2T
T/B Ver. 1.2.1
CLOSE
123
E
[ABS]
[USER]
[BRAKE]
[INITIALIZE]
[POWER]
[CLOCK]
[VERSION]
BDC
4. ABS method
2. Battery and switch-on time
3. Set date/time
5. Set/Initialize
5. USER menu
2. Release brake
1. Initialize
4. Version display
