System overview System configuration
SD-/SQ series 2 - 3
2.2 System configuration
This section describes the components required for the basic configuration of a robot system.
2.2.1 SD series
R001778E
Fig. 2-3: Configuration of an SD series robot system
NOTE The Teaching Box is an optional extra. It is required for manual operation of the robot.
5-axis articulated arm
6-axis articulated arm SCARA
Cable set
Control unit
Teaching Box R32TB
(optional)
or
or
