1 SPECIFICATIONS
1.1 General Specifications
General specifications of the Motion controller are shown below.
*1 Do not use or store the Motion controller under pressure higher than the atmospheric pressure of altitude 0m.
Doing so can cause an operation failure. When using the Motion controller under pressure, please contact
with our sales representative.
*2 This indicates the section of the power supply to which the equipment is assumed to be connected between
the public electrical power distribution network and the machinery within premises.
Category applies to equipment for which electrical power is supplied from fixed facilities. The surge voltage
withstand level for up to the rated voltage of 300V is 2500V.
*3 This index indicates the degree to which conductive material is generated in terms of the environment in which
the equipment is used.
Pollution level 2 is when only non-conductive pollution occurs. A temporary conductivity caused by
condensing must be expected occasionally.
Item Specification
Operating ambient
temperature
0 to 55 (32 to 131)
Storage ambient
temperature
-25 to 75 (-13 to 167)
Operating ambient
humidity
5 to 95% RH, non-condensing
Storage ambient
humidity
5 to 95% RH, non-condensing
Vibration resistance Compliant
with JIS B
3502 and
IEC 61131-2
Frequency Constant
acceleration
Half
amplitude
Sweep count
Under
intermittent
vibration
5 to 8.4Hz 3.5mm
(0.14inch)
10 times
each in X, Y,
Z directions
8.4 to 150Hz 9.8m/s2
Under
continuous
vibration
5 to 8.4Hz 1.75mm
(0.07inch)
8.4 to 150Hz 4.9m/s
2
Shock resistance Compliant with JIS B 3502 and IEC 61131-2 (147m/s
2
, 3 times in each of 3 directions
X, Y, Z)
Operating ambience No corrosive gases
Operating altitude
*1
2000m (6561.68ft.) or less
Mounting location Inside control panel
Overvoltage category
*2
or less
Pollution level
*3
2 or less
