24VDC power supply cable
Precautions for handling the 24VDC power supply cable
Firmly hold the 24VDC power supply connector during connection or removal of the 24VDC
power supply cable.
Connection of the 24VDC power supply cable
When connecting the 24VDC power supply cable to the Motion controller, hold the cable
connector and attach it to the Motion controller 24VDC power supply connector.
Be sure to insert it until it clicks.
Removal of the 24VDC power supply cable
When removing the 24VDC power supply cable, firmly hold the connector while pulling out the
cable.
Motion controller
