2. SYSTEM CONFIGURATION

2 - 9

MELSEC-

(2) Utility package

(a) The applicable utility packages are listed below.

•

SW0GHP-UTLPC-FN1

•

SW0GHP-UTLP-FD1

•

SW1GP-AD57P

•

SW0GHP-UTLPC-FN0

•

SW0-AD57P

•

SW0GHP-UTLPC-PID

[1] Select "A3CPU" when an SW0GHP-UTLPC-FN1 or SW0GHP-

UTLP-FD1 is started up.

[2] If both an SW1GP-AD57P and another utility package are used in

combination, specify "AD57P-COM" as the file name.

(b) The inapplicable utility package model is listed below.

•

SW0-SAPA(MELSAP)
