2. SYSTEM CONFIGURATION
2 - 8
MELSEC-
A
2.2.2 Software packages
(1) Specifying the system startup software package and startup model
(a) For AnSHCPU, startup with the PLC model "A3."
(b) Perform the PLC type setting as shown below when using conventional
peripheral devices.
CPU type
Peri
p
heral
device
Software
package
A1SJH(S8)/
A1SH
A2SH A2SH-S1
Remarks
SW[ ]IVD-GPPA *
MELSEC MEDOC
MELSEC MEDOC
plus
A3 * A3 A3
IBM PC/AT
GX Developer A1SJH/A1SH A2SH A2SH1
SW3GP-GPPAEE EPROM write not possible.
A6PHP
SW4GP-GPPAEE *
SW3-GPPAEE
SW3GP-GPPAEE
EPROM write not possible.
A6GPP
SW4GP-GPPAEE
A3 * A3 A3
*
* Selected model names differ as shown below, depending on the version of the software package:
Type For ROM writing For programming
Model name Select "A0J2H" Select "A1S" Select "A1SH" Select "A3" Select "A1SH"
SW4GP-GPPA Q or earlier R or later All versions
SW3RXV-GPPA 30D or earlier 40E or later 30D or earlier 40E or later
SW3NX-GPPA 60G or earlier 70H or later 60G or earlier 70H or later
SW3IVD-GPPA 60G or earlier 70H or later 60G or earlier 70H or later
POINT
(1) Take note that old software packages other than the SW3-GPPA, SW3-
HGPA, SW3GP-GPPA and SW4GP-GPPA cannot be used for system
startup software packages when the A6GPP/A6PHP is used.
(2) Take caution when using a software version that selects "A0J2H" or
"A1S" for ROM writing, since the file register area of 8k points is reduced
to 4k points.
To measure this, use a software package for which A1SJH/A1SH can be
selected.
