5. POWER SUPPLY MODULE
5 - 1
MELSEC-
5. POWER SUPPLY MODULE
5.1 Specifications
(1) Table 5.1 shows the specifications of the power supply modules.
Table 5.1 Power supply modules specifications
Performance specifications
Item
A1S61PN A1S62PN A1S63P
Base installation location Power supply module installation slot
Input power supply
100 to 240VAC
(85 to 264VAC)
24VDC
(15.6 to 31.2VDC)
Input frequency 50/60Hz
±
5%
Input voltage distortion factor Within 5% (See Section 8.8)
Maximum input apparent power 105VA 41W
Inrush current 20A 8ms or less 81A 1ms or less
5VDC 5A 3A 5A
Output current rating
24VDC
±
10%
0.6A
5VDC 5.5A or above 3.3A or above 5.5A or above
Overcurrent protection *1
24VDC
0.66A or above
5VDC 5.5 to 6.5V
Overvoltage protection *2
24VDC
Efficiency 65% or above
Allowable momentary power failure time *3 20ms or less 1ms or less
Between primary and
5 V DC
500VAC
Dielectric
withstand voltage
Between primary and
24 V DC
Between input: batch LG and output: batch FG, 2,830VAC
rms/3 cycle (altitude 2,000m (6562 ft)
Insulation resistance
Between input: batch LG and output: batch FG 500VAC
(10M
Ω
or above by insulation resistance tester)
10M
Ω
or above by insulation
resistance tester
Noise durability
(1) By noise simulator with noise voltage of 1,500Vp-p,
noise width of 1
µ
s, and noise frequency of 25 to 60Hz.
(2) Noise voltage IEC801-4, 2kV
By noise simulator with
noise voltage of 500Vp-p,
noise width of 1
µ
s, and
noise frequency of 25 to
60Hz.
Operation display LED display (ON for 5VDC output)
Terminal screw size M3.5
×
7
Applicable wire size 0.75 to 2mm
2
(AWG 18 to 14)
Applicable crimp-style terminal RAV1.25-3.5, RAV2-3.5
Applicable tightening torque 59 to 88N·cm
External dimensions (mm (inch)) 130 (5.12)
×
55 (2.17)
×
93.6 (3.69)
Weight (kg) 0.60 0.50
*1 Since a varistor is installed between AC and LG, do not apply a voltage of 400 volts or more between AC and LG.
+30%
-35%
+10%
-15%
