7. MEMORY CASSETTE AND BATTERY
7 - 1
MELSEC-
A
7. MEMORY CASSETTE AND BATTERY
7.1 Memory Cassette
This section describes the specifications, handling instructions and installation of
the memory ICs used in the AnSHCPU.
7.1.1 Specifications
Table 7.1 and 7.2 show the specifications of the ROMs.
Table 7.1 Memory specifications (A1SJHCPU(S8)/A1SHCPU)
Model
Item
A1SNMCA-2KE *1 A1SNMCA-8KE A1SNMCA-8KP
Memory specifications E
2
PROM EPROM
Memory capacity 8 k bytes (max. 2 k steps) 32 k bytes (max. 8 k steps) 32 k bytes (max. 8 k steps)
E
2
PROM service life for writing
10000 times 100000 times

Outside dimension [mm (in.)] 15
×
69.6
×
40.5 (0.59
×
2.75
×
1.59)
Weight [kg] 0.03
Table 7.2 Memory specifications (A2SHCPU)
Model
Item
A2SNMCA-30KE
Memory specifications E
2
PROM
Memory capacity
64 k bytes
A2SHCPU : (max. 14 k steps)
A2SHCPU-S1 : (max. 30 k steps)
E
2
PROM service life for writing
100000 times
Outside dimension [mm (in.)]
15
×
69.6
×
40.5 (0.59
×
2.75
×
1.59)
Weight [kg] 0.03
POINT
*1: When writing a program to the A1SNMCA-2KE,set the parameter for
main sequence program capacity to 2k steps or less.
Programs written with a main sequence program capacity setting of 3k
steps or over cannot work properly.
Checking between the AnSHCPU and a peripheral device will result in a
mismatch.
