2. SYSTEM CONFIGURATION
2 - 10
MELSEC-
A
2.3 System Equipment
The following table shows the list of modules and devices which can be used for an
AnS system.
(1) AnSCPU dedicated modules
Item Model Description
Number of
in
p
uts/out
p
uts
Current
consumption Remarks
*
Approved
[I/O allocation
module type]
5 V DC 24 V DC
standard
A1SJHCPU
Number of I/O points : 256, memory
capacity : 64 k bytes, Number of I/O slots
: 5
A1SJHCPU-
S8
Number of I/O points : 256, memory
capacity : 64k bytes, Number of I/O slots :
8
A1SHCPU
Number of I/O points : 256, memory
capacity : 64 k bytes
—0.30
RAM memory
embedded
A2SHCPU
Number of I/O points : 512, memory
capacity : 64 k bytes
CPU
module
A2SHCPU-S1
Number of I/O points : 1024, memory
capacity : 192 k bytes
—0.40
—
RAM memory
embedded
UL/cUL
A1S61PN 5 V DC, 5 A
A1S62PN
5 V DC, 3 A/24 V DC
0.6A
Input
100/200 V AC
———
Power
supply
module
A1S63P
5 V DC, 5 A
Input 24 V DC
———
Loaded to the
slot for main
base or
extension
base power
supply
.
A1SX10 16-point 100 to 120 V AC input module 16 [16 inputs] 0.05 —
ASX10EU 16-point 100 to 120 V AC input module 16 [16 inputs] 0.05 —
A1SX20 16-point 200 to 240 V AC input module 16 [16 inputs] 0.05 —
A1SX20EU 16-point 200 to 240 V AC input module 16 [16 inputs] 0.05 —
A1SX30
16-point 12/24 V DC, 12/24 V AC input
module
16 [16 inputs] 0.05
—
A1SX40 16-point 12/24 VDC input module 16 [16 inputs] 0.05 —
UL/cUL
A1SX40-S1 16-point 24 V DC input module 16 [16 inputs] 0.05 —
A1SX40-S2 16-point 24 V DC input module 16 [16 inputs] 0.05 —
A1SX41 32-point 12/24 V DC input module 32 [32 inputs] 0.08 —
A1SX41-S1 32-point 24 V DC input module 32 [32 inputs] 0.12 —
A1SX41-S2 32-point 24 V DC input module 32 [32 inputs] 0.08 —
A1SX42 64-point 12/24 V DC input module 64 [64 inputs] 0.09 —
A1SX42-S1 64-point 24 V DC input module 64 [64 inputs] 0.16 —
UL/cUL
A1SX42-S2 64-point 24 V DC input module 64 [64 inputs] 0.09 —
A1SX71 32-point 5/12/24V DC input module 32 [32 inputs] 0.075 —
A1SX80
16-point 12/24 V DC sink/source input
module
16 [16 inputs] 0.05
—
A1SX80-S1
16-point 24 V DC sink/source input
module
16 [16 inputs] 0.05 —
A1SX80-S2 16-point 24 V DC input module 16 [16 inputs] 0.05 —
A1SX81
32-point 12/24 V DC sink/source input
module
32 [32 inputs] 0.08 —
A1SX81-S2 32-point 24 V DC input module 32 [32 inputs] 0.08 —
Input
module
A1SX82-S1
64-point 24 V DC sink/source input
module
64 [64 inputs] 0.16
—
UL/cUL
* : Class 2 power supply recognized by the UL/cUL Standard is required for 5/12/24 V DC modules.
