Mitsubishi A1SJH User Manual

2. SYSTEM CONFIGURATION
2 - 13
MELSEC-
A
Item Model Description
Number of
inputs/outputs
Current
consumption Remarks
*
Approved
[I/O allocation
module type]
5 V DC 24 V DC
standard
Memory
card
interface
module
A1SD59J-S2 Memory card interface module
32
[Special 32-point]
0.05 —
Current
consumption
is when
A1SD59J-MIF
is connected.
A1SJ71E71N-
B2
10 base 2 (Cheapernet)
32
[Special 32-point]
0.64
—
Ethernet
interface
module
A1SJ71E71N-
B5T
10 base 5 (Ethernet), 10 base T
32
[Special 32-point]
0.42 —
A1SD70
For 1-axis position control, speed control,
speed position control.
Analog voltage output ( 0 to ± 10 V)
32
[Special 32-point]
0.3 —
A1SD71-S2
For position control, for speed control, for
speed position control.
Pulse train output, 2 axes
(independent/simultaneous 2-axis control,
direct interpolation)
48
[Special 48-point]
0.8 —
A1SD71-S7
Allows alteration of the output speed
setting of a manual pulse generator
for position control.
Pulse train output, 2 axes
(
inde
p
endent/simultaneous 2-axis control,
direct interpolation)
48
[Special 48-point]
0.8 —
A1SD75P1-
S3
Used for positioning control
Pulse output, 1 axis
32
[Special 32-point]
0.7 —
A1SD75P2-
S3
Used for positioning control
Pulse output, 2 axes
(independent, dual-axis simultaneous,
linear interpolation, circular interpolation)
32
[Special 32-point]
0.7 —
A1SD75P3-
S3
Used for positioning control
Pulse output, 3 axes
(independent, triple-axis simultaneous,
dual-axis linear interpolation, dual-axis
circular interpolation)
32
[Special 32-point]
0.7 *
—
When
differential
driver is
connected
: 0.78
UL/cUL
A1SD75M1
Used for positioning control
Digital output. For MR-H-B/MR-J-B/MR-
J2-B. 1 axis, SSCNET
32
[Special 32-point] 0.7 —
A1SD75M2
Used for positioning control
Digital output. For MR-H-B/MR-J-B/MR-
J2-B. 2 axes, SSCNET
(independent, dual-axis simultaneous,
linear interpolation, circular interpolation)
32
[Special 32-point]
0.7 —
Position-
ing
module
A1SD75M3
Used for positioning control
Digital output. For MR-H-B/MR-J-B/MR-
J2-B. 3 axes, SSCNET
(independent, triple-axis simultaneous,
dual-axis linear interpolation, dual-axis
circular interpolation)
32
[Special 32-point]
0.7 —
Position
detection
module
A1S62LS Absolute position detection module
32
[Special 32-point]
0.55 —
PLC
easier
monitoring
module
A1SS91 PLC easier monitoring module
32
[Special 32-point]
0.08 —
A1SD35ID1
ID interface module
Reader/writer connection : 1
32
[Special 32-point]
0.25 0.17
ID
interface
module
A1SD35ID2
ID interface module
Reader/writer connection : 2
32
[Special 32-point]
0.25 0.33
Paging
module
A1SD21-S1
Number of entries for calling control
trigger device
2000 : maximum word number of 40
(Half-character)
1120 : maximum word number of 80
(Half-character)
Number of entries for receiver number: 1000
32
[Special 32-point]
0.14 —
UL/cUL
* : Class 2 power supply recognized by the UL/cUL Standard is required for 5-12-24 V DC modules.
