2. SYSTEM CONFIGURATION
2 - 16
MELSEC-
Item Model Description
Number of
in
uts/out
uts
Current
consumption Remarks
*
A
roved
[I/O allocation
module type]
5 V DC 24 V DC
standard
A985GOT
Large-size graphic operation terminal
256 colors, TFT color, 800
×
600 dots,
high intensity
32 [Special 32-
point]
0.22
—
When bus-
connected
A975GOT
Large-size graphic operation terminal
256 colors, TFT color, 640
×
480 dots,
high intensity
32 [Special 32-
point]
0.22
—
When bus-
connected
A970GOT
Large-size graphic operation terminal
16 colors, TFT color, 640
×
480 dots, high
intensity/16 colors, TFT color, 640
×
480
dots, wide viewing angle/8 colors, STN
color, 640
×
480 dots/2 colors, STN
monochrome, 640
×
480 dots
32 [Special 32-
point]
0.22
—
When bus-
connected
A960GOT
Large-size graphic operation terminal
2 colors, EL, 640
×
400 dots
32 [Special 32-
point]
0.22
—
When bus-
connected
A956GOT
Medium-size graphic operation terminal
8 colors, STN color, 320
×
240 dots/STN
monochrome, 320
×
240 dots/256 colors,
TFT color, 320
×
240 dots
32 [Special 32-
point]
0.22
—
When bus-
connected
A956WGOT
Medium-size graphic operation terminal
256 colors, TFT color, 480
×
234 dots
32 [Special 32-
point]
0.22
—
When bus-
connected
A953GOT
Medium-size graphic operation terminal
8 colors, STN color, 320
×
240 dots/STN
monochrome, 320
×
240 dots/256 colors,
TFT color, 320
×
240 dots
———
For RS-232C
connected
A951GOT
Medium-size graphic operation terminal
8 colors, STN color, 320
×
240 dots/STN
monochrome, 320
×
240 dots/256 colors,
TFT color, 320
×
240 dots
32 [Special 32-
point]
0.22
—
When bus-
connected
Graphic
operation
terminal
A950GOT
Medium-size graphic operation terminal
8 colors, STN color, 320
×
240 dots/STN
monochrome, 320
×
240 dots/256 colors,
TFT color, 320
×
240 dots
———
For RS-422
connected
* : Class 2 power supply recognized by the UL/cUL Standard is required for 5-12-24 V DC modules.
To Next Page
