2. SYSTEM CONFIGURATION
2 - 19
MELSEC-
A
REMARK
I/O cables with connectors for I/O modules with 40-pin connector specifications (A1SX41, A1SX42,
A1SY41, A1SY42, etc.) or 37-pin D-sub connector specifications (A1SX81, A1SY81, A1SY81EP) are
available.
Consult your nearest Mitsubishi representative for I/O cables with connectors.
(2) Peripheral devices
Item Module Remarks
Plasma handy
Graphic
programmer
A6PHP-SET
•
Main body of A6PHP
•
SW[ ]GP-GPPAEE : A-series GPP function system disk
•
SW[ ]GP-GPPKEE : K-series GPP function system disk
•
SW0-GPPU : User disk (2DD)
•
AC30R4 : RS-422 cable (3 m (9.84 ft) long)
Intelligent GPP A6GPP-SET
•
Main body of A6GPP
•
SW[ ]GP-HGPAEE : A-series GPP function system disk
•
SW[ ]GP-HGPKEE : K-series GPP function system disk
•
SW0-GPPU : User disk (2DD)
•
AC30R4 : RS-422 cable (3 m (9.84 ft) long)
Composite
video cable
AC10MD
•
Connects A6GPP and monitor display. (1 m (3.28 ft) long)
AC30R4 3 m (9.84 ft) long
RS-422 cable
AC300R4 30 m (98.4 ft) long
Used for storing user program (3.5 in., formatted)
SW0-GPPU 2DD
User disk
SW0S-USER 2HD
Connects CPU and A6GPP/A6PHP.
Cleaning disk SW0-FDC
Applicable to
A6GPP/A6PHP
Used for cleaning disk drive.
Printer
K6PR-K
A7NPR-S1
•
For printing out program circuit diagrams and various lists.
RS232C cable AC30R2
Connection cable for between A6GPP/A6PHP and printer (K6PR-K, A7NPR-
S1, and a general-purpose printer with RS-232C interface)
3m (9.84 ft.) long
Printer paper
K6PR-Y
K7PR-Y
Printer paper for K6PR(S1) and K6PR-K. 9-inch paper. 2000 sheets per unit.
Printer paper for A7PR and A7NPR. 11-inch paper. 2000 sheets per unit.
Inked ribbon for
K6PR(K)
K6PR-R Replacement inked ribbon for K6PR-K.
Inked ribbon for
A7NPR-S1
A7NPR-R Replacement inked ribbon for A7NPR-S1.
A7PUS
Read/write of the program is performed by connecting to the CPU main
module with a RS-422 cable (AC30R4-PUS). (5VDC 0.4A)
Programming module
A8PUE
Read/write of the program is performed by connecting to the CPU main
module with a RS-422 cable (AC30R4-PUS, AC20R4-A8PU). (5VDC 0.4A)
AC30R4-PUS
Connection cable for between the CPU main module and A7PUS, A8PUE.
3m (9.84 ft.) long
RS-422 cable
AC20R4-A8PU
Connection cable for between the CPU main module and A8PUE.
2m (6.56 ft.) long
P-ROM write module A6WU
Used to write the program in the CPU/A6PHP main module to a ROM, or to
read out the program in the ROM for the CPU main module.
Connect to the CPU/A6PHP with an AC30R4/AC03WU cable.
Data access module A6DU-B
Used for monitoring the CPU devices, changing the setting values/ current
values, and displaying the operation status. (5VDC 0.23A)
Connect to the CPU with an AC30R4-PUS cable.
AC30R4
AC300R4
Connection cable for between the CPU main module and A6WU. 3m/30m
(9.84 ft./98.43 ft.) long.
RS-422 cable
AC03WU
Connection cable for between the A6PHP main module and A6WU. 0.3m
(0.98 ft.) long.
