4. AnSHCPU MODULE
4 - 2
MELSEC-
Table 4.1 Performance specifications (Continued)
Type
Item
A1SJHCPU A1SJHCPU-
S8
A1SHCPU A2SHCPU(S1)
Index register (V, Z) (points) 2 (V, Z)
Pointer (P) (points) 256 (P0 to P255)
Interrupt pointer (I) (points) 32 (I0 to I31)
Special relay (M) (points) 256 (M9000 to M9255)
Special register (D) (points) 256 (D9000 to D9255)
Comment (points) (Specify in
batches of 64 points)
Max. 3648
Self-diagnostic functions
Watchdog error monitor, Memory error detection, CPU error detection, I/O error detection,
Battery error detection, etc.
Operation mode at the time of error STOP/CONTINUE
STOP
→
RUN output mode Output data at time of STOP restored/data output after operation execution
Clock function
Year, month, day, hour, minute, second (Automatically recognises leap years.)
Accuracy -3.1 to +5.3 s (TYP. +1.7 s)/d at 0
°
C
-1.6 to +5.3 s (TYP. +2.4 s)/d at 25
°
C
-9.6 to +3.6 s (TYP. -2.1 s)/d at 55
°
C
Allowable momentary power
interruption time
20 msec (1 ms or less for the A1563P only. 100 V AC or more for the A1SJHCPU.)
Current consumption (5 V DC) 0.3 A 0.3 A 0.4 A
Weight [kg (lb.)] 1.00 (2.20) 1.06 (2.33) 0.33 (0.73) 0.33 (0.73)
Standard UL/cUL
*1 The I/O device after the actual input points can be used as MELSECNET(/B), MELSECNET/MINI, or C.C-
Link.
*2 The maximum total memory that can be used for parameters, T/C set values, program capacity, file
registers, number of comments, sampling trace, and status latch is 32 k/64 k bytes. The memory capacity
is fixed. No expansion memory is available. Section 4.1.7 shows how to calculate the memory capacity.
To Next Page
