5. POWER SUPPLY MODULE
5 - 4
MELSEC-
A
5.2 Part Identification and Setting
The following gives the names and description of the parts of the power supply
modules :
MELSECA1S61PN
POWER
MITSUBISHI
INPUT
100–240VAC
105VA
50/60Hz
INPUT
100–240VAC
105VA
50/60Hz
OUTPUT
5VDC 5A
(FG)
(LG)
INPUT
100–240VAC
(1) A1S61PN
MELSECA1S62PN
POWER
MITSUBISHI
OUTPUT
5VDC 3A
24VDC 0.6A
24G
+24V
(2) A1S62PN
A1S61PN
INPUT
100–240VAC
A1S62PN
(FG)
(LG)
[9]
[8]
[1]
[3]
[4]
[6]
[7]
[9]
[8]
[1]
[3]
[2]
[4]
[6]
[7]
NC
NC
MELSECA1S63P
POWER
MITSUBISHI
INPUT
DC15.6 –31.2V
OUTPUT
DC 5V 5A
FG
LG
+24V
INPUT
24G
(3) A1S63P
[9]
[8]
[1]
[3]
[5]
[4]
[7]
NC
NC
No. Name Description
[1] POWER LED The indicator LED for the 5 V DC power.
[2]
24 V and 24 G
terminals
Used to supply 24 V DC to inside the output module (using external wiring).
[3] FG terminal The grounding terminal connected to the shield pattern of the printed circuit board.
