7. MEMORY CASSETTE AND BATTERY

7 - 4

MELSEC-

(2) Removing a memory cassette

A1SHCPU

A1SNMCA

-8KE

Hook releasing lugs

A1SHCPU

A1SNMCA

-8KE

A1SJHCPU A1SJHCPU

Hook releasing lugs

(a) Pull out the memory cassette while pushing the hook releasing lugs that

are provided at the top and the bottom of the memory cassette.
