8. LOADING AND INSTALLATION

8 - 12

MELSEC-

(2) Removal

I/O module

Dustproof cover

Notch

Fit the tip of a flat blade screwdriver into the notch on the left side of the dustproof

cover. While keeping the screwdriver tip in the notch, gently move the screwdriver

to the left (as shown above) until the cover snaps open.
