NOTE
l
Except for diesel-powered 1600 models, to
replenish with the distilled water, remove the
upper cover and duct.
Refer to “Removing and installing the upper
cover and duct” on page 10-09.
Removing and installing the
upper cover and duct
WARNING
l
Turn the ignition switch to the “LOCK”
position or put the operation mode in
OFF.
Make sure that your clothes cannot be
caught by the fan or drive belt. Personal
injury could result.
To remove
1. Remove the clips (A), and then remove
the upper cover (B).
2.
Remove the clips (C), and then remove
the air duct (D).
To install
1. Install the air duct (A), and then tighten
the clips (B).
2.
Turn the upper cover over. Squeeze the
head of the moulding clip (C) with pliers
and remove the moulding.
3. Install the upper cover, and then attach
the moulding (D).
Battery
10-09
OGAE19E1
Maintenance
10
