Instruments and controls
17
16
1
2
3
4
5
6
7
8
9
10
11
12
15
14
13
LHD
1. Combination headlamps and dipper switch p. 5-49
Turn-signal lever p. 5-59
Front fog lamp switch* p. 5-60
Rear fog lamp switch p. 5-60
2. Instruments p. 5-02
3. Shift paddles* p. 6-23
4. Windscreen wiper and washer switch p. 5-61
Rear window wiper and washer switch p. 5-65
Headlamp washer switch* p. 5-66
5. Engine switch* p. 3-13
6. Cruise control switches* p. 6-41
7. Ignition switch* p. 6-11
8. Supplemental restraint system (SRS) - driver’s knee airbag*
p. 4-24, 4-29
9. Supplemental restraint system (SRS) - airbag (for driver’s seat)
p. 4-24, 4-28
Horn switch p. 5-67
10. Tilt & Telescopic steering lever p. 6-07
11. Bluetooth® 2.0 interface* p. 7-46
12. Steering wheel audio remote control switches* p. 7-23
13. Lane Departure Warning (LDW)* p. 6-61
14. Sonar switch* p. 6-72
15. Blind Spot Warning (BSW) ON/OFF switch* p. 6-55
16. Forward Collision Mitigation system ON/OFF switch* p. 6-50
17. Headlamp levelling switch* p. 5-57
Instruments and controls
1-02
OGAE19E1
Overview
1
To Next Page
