PU connector
● Peer-to-peer connections
● Use a switch as termination resistors cannot be connected to the inverter side of the connection.
● Connections cannot be made using the built-in Ethernet port in the CPU module.
POINT
10BASE-T cable
Terminating
resistor
Distributor
PU connector
10BASE-T
cable
