12-36 Simple inspection and service
CAUTION
Do not tighten the filter case too strongly. Over-
tightening could damage the filter case.
13. Install the sensor to the filter case and connect
the connector.
14. Bleed the fuel system. P. 13-23
15. Start the engine to test for fuel leakage.
3 Air cleaner cleaning and replacement
CAUTION
Clean the air filter at the specified cleaning
intervals. Unnecessary frequent cleaning can
damage the element, allowing dust and other
foreign matter to be drawn into the engine.
NOTE:
Even if the cleaning interval has not elapsed, clean
or replace the element if clogging of the element
causes a decrease in engine output.
The air cleaner is located in the illustrated position.
Sensor tightening
torque
5 ± 1 N·m (3.7 ± 0.7 ft.lbs.,
0.5 ± 0.1 kgf·m)
Cleaning intervals
Every 5,000 km
(3,000 miles)
Replacement intervals
Every 40,000 km
(24,000 miles)
WARNING
When cleaning air cleaner element, wear gog-
gles and a mask to protect your eyes and res-
piratory organs from dust.
And, use a dust collector to prevent dust
from dispersing into the surroundings.
Z12059
FEFG.book Page 36 Thursday, March 10, 2005 7:30 PM
