8-4 4WD operation <FG models>
2 Selecting drive mode-transfer gear
range combinations
You can select any desired drive mode and transfer
gear range combination from among those shown
in the following table. Select the most suitable com-
bination according to the driving conditions.
3 Switching the mode-range combination
•
“2WD-HIGH” to/from “4WD-HIGH”
1. Make sure that the free-wheeling hubs on both
front wheels are in the “LOCK” position.
P. 8 -6
2. Press the front drive switch either at the “ON”
side (4WD) or “OFF” side (2WD) when the vehi-
cle is either in motion or stationary.
NOTE:
• You do not need to depress the clutch pedal
when switching from the 2WD-HIGH setting to
the 4WD-HIGH setting or vice versa.
• The mode-range setting cannot be switched
from 4WD-LOW to 2WD-HIGH. The 4WD-HIGH
setting must be selected before such switching
can take place.
• If it is difficult to switch from 2WD mode to 4WD
mode and vice versa, release the accelerator
pedal and then depress it again lightly. This will
facilitate the switching.
• During switching from 4WD mode to 2WD
mode, the system may remain in 4WD mode
even after the indicator lamp has gone out.
If this happens, release the accelerator pedal
and depress it again lightly. The switching will
then take place.
Mode-range
combination
Illumi-
nated
indica-
tor lamp
Driving conditions
2WD – HIGH – Normal road driving
4WD
HIGH
Driving on snow-covered,
frozen, or sandy roads or
other difficult roads where
running in the two-wheel
drive mode is inappropri-
ate.
LOW
Driving on steep uphill or
muddy roads or other
roads where exceptionally
good traction is required.
Z11341
Z11339
Z11342
