12 Example of Communication between Master Station
12.1 System Configuration
137
FX3U-16CCL-M User's Manual
11
Programming
12
Remote I/O Communication Example
13
Remote Device Communication Example
14
Int. Device Communication Example
15
Compound Sys. Communication Example
16
Troubleshooting
A
Version Information
B
Setting Sheet
C
Differences with FX
2N
-16CCL-M
12.1.2 Setting of remote I/O station
The figure below shows the setting of the switches in the remote I/O station.
2 (2.5 Mbps)
AJ65BTB1-16D 0 1
Unit 10 1
AJ65BTB1-16T 0 2
AJ65BTB1-16DT 0 3
Transmission speed setting switch Station number setting switch

Mitsubishi FX3U Specifications

General

Series	FX3U
Program Capacity	64k steps
Type	PLC
Power Supply	AC: 100-240V, DC: 24V
I/O Points	Up to 384 points
Communication	RS-232C, USB, Ethernet
Expansion	Supports multiple expansion modules including I/O, analog, and communication modules
Programming Language	Ladder Logic, SFC, Function Block Diagram
High-speed Processing	0.065 μs per basic instruction
Analog I/O	Available with expansion modules
Positioning Control	Up to 3 axes of positioning control
Weight	0.3 kg (Main unit)
