Mitsubishi FX3U User Manual

Appendix B: Setting Sheet
Appendix B-1 Parameter setting sheet
246
FX3U-16CCL-M User's Manual
Appendix B: Setting Sheet
Appendix B-1 Parameter setting sheet
Item Setting range
BFM No.
Default
Setting
value
Remarks
Hex. Dec.
Mode
0: Remote net ver. 1 mode
1: Remote net additional mode
2: Remote net ver. 2 mode
#0H #0 K0 -
Number of
connected units
For FX3U/FX3UC PLC
1 to 16 (units)
For FX3G PLC
1 to 12 (units)
#1H #1 K8 -
Number of
retries
1 to 7 (times) #2H #2 K3 -
Number of
automatic return
units
1 to 10 (units) #3H #3 K1 -
Operation
specification
when CPU is
down
0: Stop
1: Continue
#6H #6 K0 -
Data link
disorder station
setting
0: Hold
1: Clear
#0CH #12 K1 -
Case of CPU
STOP setting
0: Refresh
1: Clears compulsorily
#0DH #13 K0 -
Reserved
station
specification
Set to ON the bits corresponding to the station numbers to
be set as reserved.
#10H #16 K0
Station
Nos. 1 to 16
Error invalid
station
specification
Set to ON the bits corresponding to the station numbers to
be set as error invalid stations.
#14H #20 K0
Station
Nos. 1 to 16
Station
information
b15 to b12 (Station type)
0H: Ver. 1 compatible remote I/O station
1H: Ver. 1 compatible remote device station
2H: Ver. 1 compatible intelligent device station
5H: Ver. 2 compatible single remote device station
6H: Ver. 2 compatible single intelligent device station
8H: Ver. 2 compatible double remote device station
9H: Ver. 2 compatible double intelligent device station
BH: Ver. 2 compatible quadruple remote device station
CH: Ver. 2 compatible quadruple intelligent device station
EH: Ver. 2 compatible octuple remote device station
FH: Ver. 2 compatible octuple intelligent device station
b11 to b8 (Number of occupied stations)
1H: Occupies 1 station
2H: Occupies 2 stations
3H: Occupies 3 stations
4H: Occupies 4 stations
b7 to b0 (Station No.)
01H to 10H (1 to 16)
#20H #32 0101H 1st unit
#21H #33 0102H 2nd unit
#22H #34 0103H 3rd unit
#23H #35 0104H 4th unit
#24H #36 0105H 5th unit
#25H #37 0106H 6th unit
#26H #38 0107H 7th unit
#27H #39 0108H 8th unit
#28H #40 0000H 9th unit
#29H #41 0000H 10th unit
#2AH #42 0000H 11th unit
#2BH #43 0000H 12th unit
#2CH #44 0000H 13th unit
#2DH #45 0000H 14th unit
#2EH #46 0000H 15th unit
#2FH #47 0000H 16th unit

Mitsubishi FX3U Specifications

General

Series	FX3U
Program Capacity	64k steps
Type	PLC
Power Supply	AC: 100-240V, DC: 24V
I/O Points	Up to 384 points
Communication	RS-232C, USB, Ethernet
Expansion	Supports multiple expansion modules including I/O, analog, and communication modules
Programming Language	Ladder Logic, SFC, Function Block Diagram
High-speed Processing	0.065 μs per basic instruction
Analog I/O	Available with expansion modules
Positioning Control	Up to 3 axes of positioning control
Weight	0.3 kg (Main unit)
