16 Troubleshooting
16.1 Troubleshooting procedure
238
FX3U-16CCL-M User's Manual
Remote input (RX) in an
intelligent device station
cannot be received.
Is the intelligent device station executing data link?
Check the following:
• Check the LED display on the
corresponding intelligent device station.
• Check the other station data link status of
the master station (SW0080).
Is data read from the correct address of remote input
RX (buffer memory)?
Confirm the sequence program.
Is the corresponding station set as a reserved station?
Check the following:
• Check the parameters.
• Check the reserved station specified status
(SW0074).
Does the station number overlap?
Check the following:
• Check the station number setting.
• Check the loading status (SW0069).
• Check the station number overlap status
(SW0098).
Do the settings match?
Check the following:
• Check the loading status (SW0069).
• Check the station number overlap status
(SW0098).
• Check the loading/parameter consistency
status (SW009C).
Remote output (RY) in an
intelligent device station
cannot be set to ON or OFF.
Is the intelligent device station executing data link?
Check the following:
• Check the LED display on the
corresponding intelligent device station.
• Check the other station data link status of
the master station (SW0080).
Is the refresh command output (BFM#10 b0) ON in the
master station?
Confirm the sequence program.
Is data written to the correct address of remote output
RY (buffer memory)?
Confirm the sequence program.
Is the corresponding station set as a reserved station?
Check the following:
• Check the parameters.
• Check the reserved station specified status
(SW0074).
Does the station number overlap?
Check the following:
• Check the station number setting.
• Check the loading status (SW0069).
• Check the station number overlap status
(SW0098).
Do the settings match?
Check the following:
• Check the loading status (SW0069).
• Check the station number overlap status
(SW0098).
• Check the loading/parameter consistency
status (SW009C).
Data in remote register (RWr)
in an intelligent device station
cannot be received.
Is the intelligent device station executing data link?
Check the following:
• Check the LED display on the
corresponding intelligent device station.
• Check the other station data link status of
the master station (SW0080).
Is data read from the correct address of remote register
RWr (buffer memory)?
Confirm the sequence program.
Is the corresponding station set as a reserved station?
Check the following:
• Check the parameters.
• Check the reserved station specified status
(SW0074).
Does the station number overlap?
Check the following:
• Check the station number setting.
• Check the loading status (SW0069).
• Check the station number overlap status
(SW0098).
Do the settings match?
Check the following:
• Check the loading status (SW0069).
• Check the station number overlap status
(SW0098).
• Check the loading/parameter consistency
status (SW009C).
Trouble description Details to be checked Confirmation method
