FX3UC-4AD (4-channel Analog Input)
2.3 Performance Specifications
*1. Adjustment of the offset or gain value will not affect the resolution. In the direct indication mode, however, the
offset/gain cannot be adjusted.
*2. The offset and the gain should satisfy the following condition:
1V ≤ (Gain - Offset)
*3. The offset and the gain should satisfy the following condition:
3 mA ≤ (Gain - Offset) ≤ 30 mA
*4. The resolution and the input/output characteristics depend on the selected mode.
Item
Specifications
Voltage input Current input
Analog input range
-10V to +10V DC
(Input resistance: 200kΩ)
-20mA to +20mA DC, 4mA to 20mA DC
(Input resistance: 250Ω)
Offset
*1
-10V to +9V
*2
-20mA to +17mA
*3
Gain
*1
-9V to +10V
*2
-17mA to +30mA
*3
Absolute maximum
input
±15V ±30mA
Digital output With sign, 16bits, binary With sign, 15bits, binary
Resolution
*4
0.32mV (20V / 64,000)
2.5mV (20V / 8,000)
1.25µA (40mA / 32,000)
5.00µA (40mA / 8,000)
Overall accuracy
• Ambient temperature: 25°C±5°C
±0.3% (±60mV) for full scale of 20V
• Ambient temperature: 0°C±55°C
±0.5% (±100mV) for full scale of 20V
• Ambient temperature: 25°C±5°C
±0.5% (±200µA) for full scale of 40mA
Same (±200µA) when input is 4mA to 20mA
• Ambient temperature: 0°C±55°C
±1% (±400µA) for full scale of 40mA
Same (±400µA) when input is 4mA to 20mA
Time required for
A/D conversion
500µs × number of selected channels
(If 1 or more channels use the digital filter(s): 5ms × number of selected channels)
Insulation method
• The photo-coupler is used to insulate the analog input area from the PLC.
• The DC/DC converter is used to insulate the analog input area from the power supply unit.
• Channels are not insulated from each other.
Number of I/O
occupied points
8 points (Count either the input or output points of the PLC.)
