3 Wiring
3.2 Power Supply Line
FX 3U /FX 3UC Series PLC User's Manual - Analog Control Edition
FX3UC-4AD (4-channel Analog Input)
3.2 Power Supply Line
3.2.1 Connection of power cable to power connector
The power crossover cable (type "C" shown in the following table) is supplied with 4AD.
To connect the power cable, refer to the User's Manual - Hardware Edition of the PLC main unit.
There are 3 types of power cables as shown in the following table. Types "A" and "B" are supplied with the
main unit, and type "C" is supplied with the input extension blocks or the special function blocks for FX
3UC
Series.
The crossover cable (type "C") can skip up to 4 16-point output blocks to connect units.
If more blocks should be skipped to supply power to an input block, use cable type "B".
<Self-made power cable>
To use self-made power cables, use the following wire rods and connectors:
Supply the 24V DC power to 4AD via the power supply connector.
Type Application Model Length Cable supplied with
A Power cable for main unit FX
2NC-100MPCB
1m
(3’ 3")
FX
3UC Series PLC main unit
B
Input power cable for input
extension block
FX
2NC-100BPCB
1m
(3’ 3")
C
Input power crossover cable for
input extension block
FX
2NC-10BPCB1
0.1m
(0’ 3")
• Input extension block for FX
2NC
Series
• Special function block for FX
3UC/
FX
2NC Series
Specifications/model
Wire size
AWG24 (0.2mm
2
)
Crimp-style terminal 50083-8014 (manufactured by Molex Japan Co., Ltd.)
Housing
For main unit 51030-0330 (manufactured by Molex Japan Co., Ltd.)
For input extension block 51030-0230 (manufactured by Molex Japan Co., Ltd.)
