Appendix1 OPERATION PROCESSING TIME
Appendix 1.2 Operation Processing Time of Basic Model QCPU
Appendix 1.2 Operation Processing Time of Basic Model
QCPU
The processing time for the individual instructions are shown in the table on the following pages.
Operation processing times can vary substantially depending on the nature of the sources and
destinations of the instructions, and the values contained in the following tables should therefore
be taken as a set of general guidelines to processing time rather than as being strictly accurate.
(1) Sequence instructions
Instruction Condition (Device)
Processing Time (µs)
Q00JCPU Q00CPU Q01CPU
LD
LDI
AND
ANI
OR
ORI
X0 0.20 0.16 0.10
D0.0 0.30 0.24 0.15
LDP
LDF
ANDP
ANDF
ORP
ORF
X0
0.30 0.24 0.15
D0.0
ANB
ORB
MPS
MRD
MPP
––
0.20 0.16 0.10
INV
When not executed
0.20 0.16 0.10
When executed
MEP
MEF
When not executed
0.30 0.24 0.15
When executed
EGP
When not executed
(OFF OFF)
(ON ON)
0.20 0.16 0.10
When executed
(OFF ON)
(ON OFF)
EGF
When not executed
(OFF OFF)
(ON ON)
17 9.5 9.4
When executed
(OFF ON)
(ON OFF)
18 14 14
