7-142

CCOM

7.6.11 Select Refresh Instruction (CCOM(P))

CCOM

Function

See 7.6.10 for details about function.

Operation Error

(1) When the CCOM(P) instruction is executed in the QnUD(H)CPU whose serial number

(first five digits) is "10101" or later, an error occurs. (Error code: 4100)

Program Example

(1) Turning on M0 enables the program to execute the select refresh, while turning off M0

disables the program to execute the select refresh.

[Ladder Mode] [List Mode]

QnU(D)(H)CPU: The serial number (first five digits) is "10102" or later.

QnUDE(H)CPU: The serial number (first five digits) is "10102" or later.

Setting

Data

Internal Devices

Z, ZR

U\G

Zn Constants Other

Bit Word Bit Word

–– ––

Basic

Process

High

performance

Redundant

Ver.

Universal

LCPU

CCOM

CCOMP

CCOM

CCOMP

Command

Step

Instruction

Device
