Appendix1 OPERATION PROCESSING TIME Appendix 1.2 Operation Processing Time of Basic Model QCPU
(5) Instructions executable by the product with the first 5 digits of the serial No. "04122" or higher
Instruction Condition (Device)
Processing Time (µs)
Q00JCPU Q00CPU Q01CPU
LDE =
Single precision
In conductive status 43.0 35.5 33.0
In non-conductive status 46.0 38.0 35.5
ANDE =
Single precision
When not executed 1.5 1.2 1.0
When executed
In conductive status 35.5 29.5 26.5
In non-conductive status 42.0 35.0 32.5
ORE =
Single precision
When not executed 1.5 1.2 1.0
When executed
In conductive status 42.0 35.0 32.5
In non-conductive status 37.0 31.0 28.5
LDE < >
Single precision
In conductive status 46.0 38.0 35.5
In non-conductive status 43.5 36.0 33.0
ANDE < >
Single precision
When not executed 1.5 1.2 1.0
When executed
In conductive status 38.5 31.5 29.0
In non-conductive status 39.5 33.0 30.5
ORE < >
Single precision
When not executed 1.5 1.2 1.0
When executed
In conductive status 45.0 37.5 35.0
In non-conductive status 34.5 29.0 26.5
LDE >
Single precision
In conductive status 46.0 37.5 35.5
In non-conductive status 46.0 38.5 35.0
ANDE >
Single precision
When not executed 1.5 1.2 1.0
When executed
In conductive status 38.5 32.0 29.0
In non-conductive status 42.0 35.0 32.5
ORE >
Single precision
When not executed 1.5 1.2 1.0
When executed
In conductive status 45.0 37.5 34.5
In non-conductive status 37.0 31.0 29.0
LDE < =
Single precision
In conductive status 45.5 37.5 35.0
In non-conductive status 46.5 38.5 35.5
ANDE < =
Single precision
When not executed 1.5 1.2 1.0
When executed
In conductive status 38.5 31.5 29.0
In non-conductive status 42.5 35.5 32.5
ORE < =
Single precision
When not executed 1.5 1.2 1.0
When executed
In conductive status 45.0 37.5 34.5
In non-conductive status 37.5 31.5 28.5
LDE <
Single precision
In conductive status 45.5 37.5 35.0
In non-conductive status 46.5 38.5 35.5
ANDE <
Single precision
When not executed 1.5 1.2 1.0
When executed
In conductive status 38.0 31.5 29.0
In non-conductive status 42.5 35.5 32.5
ORE <
Single precision
When not executed 1.5 1.2 1.0
When executed
In conductive status 45.0 37.5 34.5
In non-conductive status 37.5 31.5 29.0
LDE > =
Single precision
In conductive status 45.5 38.0 35.5
In non-conductive status 46.5 38.0 35.0
ANDE > =
Single precision
When not executed 1.5 1.2 1.0
When executed
In conductive status 38.5 32.0 29.0
In non-conductive status 42.5 35.5 32.5
