Appendix1 OPERATION PROCESSING TIME
Appendix 1.3
Operation Processing Time of High Performance Model QCPU/Process CPU/Redundant CPU
(3) Application instructions
The processing time when the instruction is not executed is calculated as follows:
Q02CPU
·······················································0.079 (No. of steps for each instruction + 1) µs
Q02HCPU, Q06HCPU, Q12HCPU, Q25HCPU, Q02PHCPU, Q06PHCPU, Q12PHCPU,
Q25PHCPU, Q12PRHCPU, Q25PRHCPU
······································································0.034 (No. of steps for each instruction + 1) µs
Instruction Condition (Device)
Processing Time ( µs)
Qn QnH QnPH QnPRH
WAND
WANDP
When executed 0.39 0.17 0.17 0.17
WAND
WANDP
When executed 0.47 0.20 0.20 0.20
DAND
DANDP
When executed 0.71 0.31 0.31 0.31
DAND
DANDP
When executed 0.79 0.34 0.34 0.34
BKAND n
n = 1 36161616
BKANDP n
n = 96 74 32 32 32
WOR
WORP
When executed 0.40 0.17 0.17 0.17
WOR
WORP
When executed 0.47 0.20 0.20 0.20
DOR
DORP
When executed 0.71 0.31 0.31 0.31
DOR
DORP
When executed 0.79 0.34 0.34 0.34
BKOR n
n = 1 36161616
BKORP n
n = 96 74 32 32 32
WXOR
WXORP
When executed 0.39 0.17 0.17 0.17
WXOR
WXORP
When executed 0.47 0.20 0.20 0.20
DXOR
DXORP
When executed 0.71 0.31 0.31 0.31
DXOR
DXORP
When executed 0.79 0.34 0.34 0.34
BKXOR n
n = 1 36161616
BKXORP n
n = 96 74 32 32 32
S D
S D
S1
S2
D
S1
S2
D
S D
S D
S1
S2
D
S1
S2
D
S1
S2
D
S1
S2
D
S D
S D
S1
S2
D
S1
S2
D
S D
S D
S1
S2
D
S1
S2
D
S1
S2
D
S1
S2
D
S D
S D
S1
S2
D
S1
S2
D
S D
S D
S1
S2
D
S1
S2
D
S1
S2
D
S1
S2
D
