Mitsubishi MELSEC Q Series Programming Manual

App-42
Instruction Condition (Device)
Processing Time (µs)
Qn QnH QnPH QnPRH
LEDC
When displayed
–– –– –– ––
Display completed
–– –– –– ––
LEDR
No display no display
0.40 0.17 0.17 0.17
LED instruction execution no display
103 44 44 44
CHKST
––
5.8 2.5 2.5 2.5
CHK
1 contact no error 24 10 10 10
150 contact no error 1676 721 721 721
1 contact error 88 38 38 38
CHKCIR
10 steps 5.8 2.5 2.5 2.5
SLT
All internal devices
–– –– –– ––
File register 8k points
–– –– –– ––
SLT execution completion
–– –– –– ––
SLTR
–– –– –– –– ––
STRA
Start
–– –– –– ––
STRA execution completion
–– –– –– ––
STRAR
–– –– –– –– ––
PTRA
–– –– –– –– ––
PTRAR
–– –– –– –– ––
PTRAEXE
PTRAEXEP
When operating
–– –– –– ––
Trace in progress
–– –– –– ––
BINDA
BINDAP
= 1
15 6.7 6.7 6.7
= - 32768
24 10 10 10
DBINDA
DBINDAP
= 1
43 18 18 18
= - 2147483648
86 37 37 37
BINHA
BINHAP
= 1
18 7.7 7.7 7.7
= FFFF
H
19 8.2 8.2 8.2
DBINHA
DBINHAP
= 1
23 10 10 10
= FFFFFFFF
H
24 10 10 10
BCDDA
BCDDAP
= 1
23 9.8 9.8 9.8
= 9999
21 8.9 8.9 8.9
DBCDDA
DBCDDAP
= 1
22 9.5 9.5 9.5
= 99999999
29 13 13 13
DABIN
DABINP
= 1
57 25 25 25
= - 32768
58 25 25 25
DDABIN
DDABINP
= 1
92 40 40 40
= - 2147483648
106 46 46 46
HABIN
HABINP
= 1
13 5.8 5.8 5.8
= FFFF
H
15 6.4 6.4 6.4
DHABIN
DHABINP
= 1
22 9.5 9.5 9.5
= FFFFFFFF
H
25 11 11 11
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
S
