Appendix1 OPERATION PROCESSING TIME Appendix 1.3
Operation Processing Time of High Performance Model QCPU/Process CPU/Redundant CPU
Instruction Condition (Device)
Processing Time (µs)
Qn QnH QnPH QnPRH
BSQR
BSQRP
= 0
6.2 2.7 2.7 2.7
= 9999
38 16 16 16
BDSQR
BDSQRP
= 0
6.2 2.7 2.7 2.7
= 99999999
38 16 16 16
BSIN
BSINP
––
12 5.1 5.1 5.1
BCOS
BCOSP
––
12 5.2 5.2 5.2
BTAN
BTANP
––
12 5.2 5.2 5.2
BASIN
BASINP
––
20 8.7 8.7 8.7
BACOS
BACOSP
––
21 9.0 9.0 9.0
BATAN
BATANP
––
22 9.6 9.6 9.6
LIMIT
LIMITP
––
10 4.3 4.3 4.3
DLIMIT
DLIMITP
––
11 4.7 4.7 4.7
BAND
BANDP
––
9.8 4.2 4.2 4.2
DBAND
DBANDP
––
11 4.9 4.9 4.9
ZONE
ZONEP
––
9.1 3.9 3.9 3.9
DZONE
DZONEP
––
11 4.6 4.6 4.6
RSET
RSETP
––
6.8 2.9 2.9 2.9
QDRSET
QDRSETP
––
205 88 88 88
QCDSET
QCDSETP
––
147 63 63 63
DATERD
DATERDP
––
13 5.5 5.5 5.5
DATEWR
DATEWRP
––
15 6.4 6.4 6.4
S
S
S
S
