Appendix1 OPERATION PROCESSING TIME Appendix 1.4 Operation Processing Time of Universal Model QCPU
Category Instruction Condition (Device)
Processing Time (µs)
Q00UJCPU Q00UCPU Q01UCPU Q02UCPU
Min. Max. Min. Max. Min. Max. Min. Max.
Basic
instruction
LD=
In conductive status
0.360 0.240 0.180 0.120
In non-conductive status
AND=
When not executed
0.360 0.240 0.180 0.120
When executed
In conductive status
In non-conductive status
OR=
When not executed
0.360 0.240 0.180 0.120
When executed
In conductive status
In non-conductive status
LD<>
In conductive status
0.360 0.240 0.180 0.120
In non-conductive status
AND<>
When not executed
0.360 0.240 0.180 0.120
When executed
In conductive status
In non-conductive status
OR<>
When not executed
0.360 0.240 0.180 0.120
When executed
In conductive status
In non-conductive status
LD>
In conductive status
0.360 0.240 0.180 0.120
In non-conductive status
AND>
When not executed
0.360 0.240 0.180 0.120
When executed
In conductive status
In non-conductive status
OR>
When not executed
0.360 0.240 0.180 0.120
When executed
In conductive status
In non-conductive status
LD<=
In conductive status
0.360 0.240 0.180 0.120
In non-conductive status
AND<=
When not executed
0.360 0.240 0.180 0.120
When executed
In conductive status
In non-conductive status
OR<=
When not executed
0.360 0.240 0.180 0.120
When executed
In conductive status
In non-conductive status
LD<
In conductive status
0.360 0.240 0.180 0.120
In non-conductive status
AND<
When not executed
0.360 0.240 0.180 0.120
When executed
In conductive status
In non-conductive status
OR<
When not executed
0.360 0.240 0.180 0.120
When executed
In conductive status
In non-conductive status
LD>=
In conductive status
0.360 0.240 0.180 0.120
In non-conductive status
AND>=
When not executed
0.360 0.240 0.180 0.120
When executed
In conductive status
In non-conductive status
OR>=
When not executed
0.360 0.240 0.180 0.120
When executed
In conductive status
In non-conductive status
