App-56
(b) When using Q03UD(E)HCPU, Q04UD(E)HCPU, Q06UD(E)HCPU,
Q10UD(E)HCPU,Q13UD(E)HCPU, Q20UD(E)HCPU, Q26UD(E)HCPU
Category Instruction Condition (Device)
Processing Time (µs)
Q03UD(E)CPU Q04/Q06UD(E)HCPU
Q10/Q13/Q20/
Q26UD(E)HCPU
Min. Max. Min. Max. Min. Max.
Sequence
instruction
LD
LDI
AND
ANI
OR
ORI
LDP
LDF
ANDP
ANDF
ORP
ORF
When executed 0.020 0.0095 0.0095
LDPI
LDFI
When executed 0.060 0.0285 0.0285
ANDPI
ANDFI
ORPI
ORFI
When executed 0.080 0.038 0.038
OUT
When not changed
0.020 0.0095 0.0095
When changed
SET
RST
When not executed 0.020 0.0095 0.0095
