Appendix1 OPERATION PROCESSING TIME Appendix 1.4 Operation Processing Time of Universal Model QCPU
(3) Table of the time to be added when F/T(ST)/C device is used in OUT/SET/RST instruction
(a) When using Q00UJCPU, Q00UCPU, Q01UCPU and Q02UCPU.
(b) When using Q03UD(E)CPU, Q04UD(E)HCPU, Q06UD(E)HCPU, Q10UD(E)HCPU,
Q13UD(E)HCPU, Q20UD(E)HCPU and Q26UD(E)HCPU
Instruction
name
Device name Condition
Processing Time (µs)
Q00UJCPU Q00UCPU Q01UCPU
Q02UCPU
OUT
F
When not executed 2.900 2.900 2.900 2.100
When executed
When displayed 116.000 116.000 116.000 68.800
Display completed 116.000 116.000 116.000 61.600
T(ST), C
When not executed 0.360 0.240 0.180 0.120
When executed
After time up 0.360 0.240 0.180 0.120
When added 0.360 0.240 0.180 0.120
SET F
When not executed 0.120 0.080 0.006 0.004
When executed
When displayed 116.000 116.000 116.000 68.600
Display completed 116.000 116.000 116.000 65.700
RST
F
When not executed 0.120 0.080 0.006 0.004
When executed
When displayed 55.800 55.800 55.800 26.500
Display completed 29.200 29.200 29.200 21.600
T(ST), C
When not executed 0.360 0.240 0.180 0.120
When executed 0.360 0.240 0.180 0.120
Instruction
name
Device name Condition
Processing Time (µs)
Q03UD(E)CPU Q04/Q06UD(E)HCPU
Q10/Q13/Q20/
Q26UD(E)HCPU
OUT
F
When not executed 1.940 1.570 1.570
When executed
When displayed 39.930 38.090 38.090
Display completed 39.750 37.980 37.980
T(ST), C
When not executed 0.060 0.030 0.030
When executed After time up 0.060 0.030 0.030
SET F
When not executed 0.000 0.000 0.000
When executed
When displayed 42.900 40.600 40.600
Display completed 39.270 37.900 37.900
RST
F
When not executed 0.000 0.000 0.000
When executed
When displayed 45.260 36.600 36.600
Display completed 19.020 16.190 16.190
T(ST), C
When not executed 0.060 0.030 0.030
When executed 0.060 0.030 0.030
