Mitsubishi MELSEC Q Series - Page 1076

App-68
Category Instruction Condition (Device)
Processing Time (µs)
Q00UJCPU Q00UCPU Q01UCPU Q02UCPU
Min. Max. Min. Max. Min. Max. Min. Max.
Basic
instruction
LDE>=
Single
precision
In conductive status
4.400 20.900 4.400 20.900 4.400 20.900 4.700 12.200
In non-conductive status
4.400 20.900 4.400 20.900 4.400 20.900 4.700 11.800
ANDE>=
Single
precision
When not executed
0.360 0.240 0.180 0.120
When
executed
In conductive status
4.200 19.600 4.200 19.600 4.200 19.600 4.100 6.700
In non-conductive status
4.200 19.600 4.200 19.600 4.200 19.600 4.400 7.000
ORE>=
Single
precision
When not executed
0.360 0.240 0.180 0.120
When
executed
In conductive status
4.200 17.400 4.200 17.400 4.200 17.400 4.600 14.000
In non-conductive status
4.200 17.400 4.200 17.400 4.200 17.400 4.500 14.300
LDED=
Double
precision
In conductive status
4.700 37.400 4.700 37.400 4.700 37.400 4.200 21.000
In non-conductive status
4.700 37.400 4.700 37.400 4.700 37.400 5.100 21.900
ANDED=
Double
precision
When not executed
0.360 0.240 0.180 0.120
When
executed
In conductive status
4.500 34.700 4.500 34.700 4.500 34.700 3.800 17.800
In non-conductive status
4.500 34.700 4.500 34.700 4.500 34.700 4.100 18.100
ORED=
Double
precision
When not executed
0.360 0.240 0.180 0.120
When
executed
In conductive status
4.700 33.200 4.700 33.200 4.700 33.200 4.100 23.800
In non-conductive status
4.700 33.200 4.700 33.200 4.700 33.200 4.900 25.500
LDED<>
Double
precision
In conductive status
4.700 37.400 4.700 37.400 4.700 37.400 5.100 23.500
In non-conductive status
4.700 37.400 4.700 37.400 4.700 37.400 4.200 22.600
ANDED<>
Double
precision
When not executed
0.360 0.240 0.180 0.120
When
executed
In conductive status
4.500 34.700 4.500 34.700 4.500 34.700 4.000 18.800
In non-conductive status
4.500 34.700 4.500 34.700 4.500 34.700 4.000 18.700
ORED<>
Double
precision
When not executed
0.360 0.240 0.180 0.120
When
executed
In conductive status
4.700 33.200 4.700 33.200 4.700 33.200 5.000 25.200
In non-conductive status
4.700 33.200 4.700 33.200 4.700 33.200 4.100 23.400
LDED>
Double
precision
In conductive status
4.700 37.400 4.700 37.400 4.700 37.400 5.100 25.100
In non-conductive status
4.700 37.400 4.700 37.400 4.700 37.400 4.200 23.400
ANDED>
Double
precision
When not executed
0.360 0.240 0.180 0.120
When
executed
In conductive status
4.500 34.700 4.500 34.700 4.500 34.700 4.000 19.500
In non-conductive status
4.500 34.700 4.500 34.700 4.500 34.700 4.100 19.700
ORED>
Double
precision
When not executed
0.360 0.240 0.180 0.120
When
executed
In conductive status
4.700 33.200 4.700 33.200 4.700 33.200 5.000 24.200
In non-conductive status
4.700 33.200 4.700 33.200 4.700 33.200 4.900 25.800
LDED<=
Double
precision
In conductive status
4.700 37.400 4.700 37.400 4.700 37.400 4.200 22.500
In non-conductive status
4.700 37.400 4.700 37.400 4.700 37.400 4.200 13.500
ANDED<=
Double
precision
When not executed
0.360 0.240 0.180 0.120
When
executed
In conductive status
4.500 34.700 4.500 34.700 4.500 34.700 4.000 19.600
In non-conductive status
4.500 34.700 4.500 34.700 4.500 34.700 4.100 19.700
ORED<=
Double
precision
When not executed
0.360 0.240 0.180 0.120
When
executed
In conductive status
4.700 33.200 4.700 33.200 4.700 33.200 5.000 26.300
In non-conductive status
4.700 33.200 4.700 33.200 4.700 33.200 5.000 25.200
