App-98
Category Instruction Condition (Device)
Processing Time (µs)
Q03UD(E)CPU
Q04/
Q06UD(E)HCPU
Q10/Q13/Q20/
Q26UD(E)HCPU
Min. Max. Min. Max. Min. Max.
Application
instruction
COM
CCOM
When selecting I/O refresh only 12.800 29.100 12.400 28.600 12.400 28.600
When selecting CC-Link refresh
only (Master station side)
16.000 39.500 15.500 39.100 15.500 39.100
When selecting CC-Link refresh
only (Local station side)
16.100 39.500 15.500 39.100 15.500 39.100
When selecting MELSECNET/H
refresh only (Control station side)
34.700 70.400 34.400 69.800 34.400 69.800
When selecting MELSECNET/H
refresh only (Normal station side)
34.700 70.400 34.400 69.800 34.400 69.800
When selecting intelli auto
refresh only
12.800 33.200 12.800 33.200 12.800 33.200
When selecting I/O outside the
group only (Input only)
7.900 21.100 7.700 20.700 7.700 20.700
When selecting I/O outside the
group only (Output only)
16.900 44.800 16.500 44.200 16.500 44.200
When selecting I/O outside the
group only (Both I/O)
22.600 52.600 22.400 52.600 22.400 52.600
When selecting refresh of multi-
ple CPU high speed transmission
area only
13.000 33.800 12.700 33.200 12.700 33.200
When selecting communication
with peripheral device
7.250 18.800 7.100 18.500 7.100 18.500
FIFW
Number of data points = 0 3.700 5.300 3.200 4.600 3.200 4.600
Number of data points = 96 3.800 4.400 3.300 3.800 3.300 3.800
FIFR
Number of data points = 0 4.300 5.000 3.800 4.400 3.800 4.400
Number of data points = 96 33.500 35.500 24.800 25.700 24.800 25.700
FPOP
Number of data points = 0 4.300 5.900 3.800 5.300 3.800 5.300
Number of data points = 96 4.300 5.900 3.700 5.400 3.700 5.400
FINS
Number of data points = 0 4.800 5.900 3.700 5.300 3.700 5.300
Number of data points = 96 4.300 5.900 3.700 5.300 3.700 5.300
FDEL
Number of data points = 0 4.900 6.500 4.200 5.800 4.200 5.800
Number of data points = 96 34.200 35.900 25.400 25.900 25.400 25.900
FROM n1 n2 n3
n3 = 1 10.800 24.100 10.700 23.600 10.700 23.600
n3 = 1000 392.600 413.300 390.900 410.200 390.900 410.200
DFRO n1 n2 n3
n3 = 1 13.600 27.700 12.600 26.700 12.600 26.700
n3 = 500 392.600 413.300 390.900 410.200 390.900 410.200
TO n1 n2 n3
n3 = 1 10.200 21.900 9.600 21.300 9.600 21.300
n3 = 1000 373.700 394.100 372.500 390.800 372.500 390.800
DTO n1 n2 n3
n3 = 1 13.000 26.700 12.000 25.700 12.000 25.700
n3 = 500 373.700 394.100 372.500 390.800 372.500 390.800
LEDR
No display no display
2.400 2.600 1.900 2.000 1.900 2.000
LED instruction execution no
display
28.100 39.400 24.400 35.800 24.400 35.800
BINDA
= 1
4.900 6.500 4.300 5.600 4.300 5.600
= -32768
7.200 8.700 6.500 8.000 6.500 8.000
DBINDA
= 1
5.700 7.100 4.900 6.300 4.900 6.300
= -2147483648
10.400 12.000 9.600 11.000 9.600 11.000
