Appendix1 OPERATION PROCESSING TIME
Appendix 1.4 Operation Processing Time of Universal Model QCPU
Category Instruction Condition (Device)
Processing Time (µs)
Q03UD(E)CPU
Q04/
Q06UD(E)HCPU
Q10/Q13/Q20/
Q26UD(E)HCPU
Min. Max. Min. Max. Min. Max.
Application
instruction
LDDT<=
Comparison
of specified
date
In conductive
status
7.400 11.400 6.800 10.900 6.800 10.900
In nonconductive
status
7.400 11.600 6.800 10.900 6.800 10.900
Comparison
of current
date
In conductive
status
5.900 10.000 5.500 9.700 5.500 9.700
In nonconductive
status
5.900 10.100 5.500 9.700 5.500 9.700
ANDDT<=
When not executed 0.008 0.038 0.038
Comparison
of specified
date
In conductive
status
7.200 11.400 6.500 10.700 6.500 10.700
In nonconductive
status
7.200 11.400 6.500 10.700 6.500 10.700
Comparison
of current
date
In conductive
status
5.700 9.900 5.300 9.300 5.300 9.300
In nonconductive
status
5.700 9.900 5.300 9.300 5.300 9.300
ORDT<=
When not executed 0.008 0.038 0.038
Comparison
of specified
date
In conductive
status
7.400 11.500 6.700 10.800 6.700 10.800
In nonconductive
status
7.400 11.500 6.700 10.800 6.700 10.800
Comparison
of current
date
In conductive
status
5.900 10.000 5.400 9.600 5.400 9.600
In nonconductive
status
5.900 10.000 5.400 9.600 5.400 9.600
LDDT<
Comparison
of specified
date
In conductive
status
7.400 11.400 6.800 10.900 6.800 10.900
In nonconductive
status
7.400 11.600 6.800 10.900 6.800 10.900
Comparison
of current
date
In conductive
status
5.900 10.000 5.500 9.700 5.500 9.700
In nonconductive
status
5.900 10.100 5.500 9.700 5.500 9.700
ANDDT<
When not executed 0.008 0.038 0.038
Comparison
of specified
date
In conductive
status
7.200 11.400 6.500 10.700 6.500 10.700
In nonconductive
status
7.200 11.400 6.500 10.700 6.500 10.700
Comparison
of current
date
In conductive
status
5.700 9.900 5.300 9.300 5.300 9.300
In nonconductive
status
5.700 9.900 5.300 9.300 5.300 9.300
ORDT<
When not executed 0.008 0.038 0.038
Comparison
of specified
date
In conductive
status
7.400 11.500 6.700 10.800 6.700 10.800
In nonconductive
status
7.400 11.500 6.700 10.800 6.700 10.800
Comparison
of current
date
In conductive
status
5.900 10.000 5.400 9.600 5.400 9.600
In nonconductive
status
5.900 10.000 5.400 9.600 5.400 9.600
