Mitsubishi MELSEC Q Series Programming Manual

App-108
Category Instruction Condition (Device)
Processing Time (µs)
Q03UD(E)CPU
Q04/
Q06UD(E)HCPU
Q10/Q13/Q20/
Q26UD(E)HCPU
Min. Max. Min. Max. Min. Max.
Application
instruction
LDTM<=
Comparison
of specified
ciock
In conductive
status
7.300 11.500 6.700 10.800 6.700 10.800
In nonconductive
status
7.300 11.500 6.700 10.800 6.700 10.800
Comparison
of current
ciock
In conductive
status
5.800 9.900 5.400 9.500 5.400 9.500
In nonconductive
status
5.800 9.900 5.400 9.500 5.400 9.500
ANDTM<=
When not executed 0.008 0.038 0.038
Comparison
of specified
ciock
In conductive
status
7.000 11.500 6.300 10.800 6.300 10.800
In nonconductive
status
7.000 11.500 6.300 10.800 6.300 10.800
Comparison
of current
ciock
In conductive
status
5.500 9.900 5.100 9.500 5.100 9.500
In nonconductive
status
5.500 9.900 5.100 9.500 5.100 9.500
ORTM<=
When not executed 0.008 0.038 0.038
Comparison
of specified
ciock
In conductive
status
7.300 11.500 6.600 10.800 6.600 10.800
In nonconductive
status
7.300 11.500 6.600 10.800 6.600 10.800
Comparison
of current
ciock
In conductive
status
5.900 9.900 5.300 9.500 5.300 9.500
In nonconductive
status
5.900 9.900 5.300 9.500 5.300 9.500
LDTM<
Comparison
of specified
ciock
In conductive
status
7.300 11.500 6.700 10.800 6.700 10.800
In nonconductive
status
7.300 11.500 6.700 10.800 6.700 10.800
Comparison
of current
ciock
In conductive
status
5.800 9.900 5.400 9.500 5.400 9.500
In nonconductive
status
5.800 9.900 5.400 9.500 5.400 9.500
ANDTM<
When not executed 0.480 0.320 0.240
Comparison
of specified
ciock
In conductive
status
8.200 25.500 8.200 25.500 6.500 25.500
In nonconductive
status
8.200 25.500 8.200 25.500 6.500 25.500
Comparison
of current
ciock
In conductive
status
6.500 23.100 6.500 23.100 6.500 23.100
In nonconductive
status
6.500 23.100 6.500 23.100 6.500 23.100
ORTM<
When not executed 0.480 0.320 0.240
Comparison
of specified
ciock
In conductive
status
8.200 25.500 8.200 25.500 6.500 25.500
In nonconductive
status
8.200 25.500 8.200 25.500 6.500 25.500
Comparison
of current
ciock
In conductive
status
6.500 23.100 6.500 23.100 6.500 23.100
In nonconductive
status
6.500 23.100 6.500 23.100 6.500 23.100
