Mitsubishi MELSEC Q Series Programming Manual

App-138
Category Instruction Condition (Device)
Processing Time (µs)
L02CPU L26CPU-BT
Min. Max. Min. Max.
Application
instruction
SCL
SM750
= ON
Point No.1 < <
Point No.2
12.500 29.200 11.900 23.000
Point No.9 < <
Point No.10
13.200 29.100 12.100 23.000
SM750
= OFF
Point No.1 < <
Point No.2
12.100 28.900 10.900 22.200
Point No.9 < <
Point No.10
13.900 30.900 12.700 23.900
DSCL
SM750
= ON
Point No.1 < <
Point No.2
12.500 29.200 11.900 23.000
Point No.9 < <
Point No.10
13.200 29.100 12.100 23.000
SM750
= OFF
Point No.1 < <
Point No.2
12.100 28.900 10.900 22.200
Point No.9 < <
Point No.10
13.900 30.900 12.700 23.900
SCL2
SM750
= ON
Point No.1 < <
Point No.2
13.400 29.700 11.800 23.300
Point No.9 < <
Point No.10
12.900 29.500 12.100 23.300
SM750
= OFF
Point No.1 < <
Point No.2
12.200 29.100 11.000 22.600
Point No.9 < <
Point No.10
13.900 30.700 12.600 23.900
DSCL2
SM750
= ON
Point No.1 < <
Point No.2
13.400 29.700 11.800 23.300
Point No.9 < <
Point No.10
12.900 29.500 12.100 23.300
SM750
= OFF
Point No.1 < <
Point No.2
12.200 29.100 11.000 22.600
Point No.9 < <
Point No.10
13.900 30.700 12.600 23.900
S1
S2
D
S1
S1
S1
S1
S1
S2
D
S1
S1
S1
S1
S1
S2
D
S1
S1
S1
S1
S1
S2
D
S1
S1
S1
S1
