App-140
(2) Table of the time to be added when file register or module access device is used
(a) When using L02CPU, L26CPU-BT
Device name data
Device Specification
Location
Processing Time (µs)
L02CPU L26CPU-BT
File register (R)
When standard
RAM is used
Bit
Source
0.100 0.048
Destination
0.220 0.038
Word
Source
0.100 0.048
Destination
0.100 0.038
Double word
Source
0.200 0.095
Destination
0.200 0.086
File register (ZR),
Extended data register (D),
Extended link register (W)
When standard
RAM is used
Bit
Source
0.140 0.057
Destination
0.280 0.048
Word
Source
0.140 0.057
Destination
0.140 0.048
Double word
Source
0.240 0.105
Destination
0.240 0.095
module access device
(Un\G )
Bit
Source
11.700 11.200
Destination
15.400 15.300
Word
Source
9.460 9.410
Destination
19.000 19.000
Double word
Source
11.000 10.900
Destination
18.800 18.700
