(2) System information
Number Name
Meaning
Explanation
Set by
(When Set)
Corres-
ponding
ACPU
M9
Corresponding
CPU
SM202
LED OFF
command
OFF→ON : LED OFF
When this relay turns on from off, the LED
corresponding to each bit in SD202 turns off.
UNew
Qn(H)
QnPH
QnPRH
QnU
LCPU
SM203 STOP contact STOP status
This relay is on when the module is in the
STOP status.
S (Status
change)
M9042
QCPU
LCPU
SM204 PAUSE contact PAUSE status
This relay is on when the module is in the
PAUSE status.
M9041
SM206
PAUSE enable
coil
OFF : PAUSE disabled
ON : PAUSE enabled
PAUSE status is entered if this relay is ON
when the PAUSE contact goes ON
U
M9040
SM210
Clock data set
request
OFF : Ignored
ON : Set request
Clock data stored in SD210 to SD213 are
written to the CPU module after the END
instruction execution in the scan where this
relay is turned on.
M9025
SM211 Clock data error
OFF : No error
ON : Error
This relay turns on if an error occurs in the
clock data (SD210 to SD213), and is off while
there is no error.
S (Request) M9026
SM213
Clock data read
request
OFF : Ignored
ON : Read request
This relay is turned on to read clock data and
store them as BCD values into SD210 to
SD213.
U M9028
SM220
CPU No.1
preparation
completed
OFF : CPU No.1
preparation
uncompleted
ON : CPU No.1
preparation
completed
Turns on when an access to CPU No.1 from
another CPU becomes possible after power-
on or reset operation. This relay is used as an
interlock for accessing CPU No.1 when the
multiple CPU synchronous setting is set to
asynchronous.
S (When status
changed)
New
QCPU
SM221
CPU No.2
preparation
completed
OFF : CPU No.2
preparation
uncompleted
ON : CPU No.2
preparation
completed
Turns on when an access to CPU No.2 from
another CPU becomes possible after power-
on or reset operation. This relay is used as an
interlock for accessing CPU No.2 when the
multiple CPU synchronous setting is set to
asynchronous.
QnU
*7
SM222
CPU No.3
preparation
completed
OFF : CPU No.3
preparation
uncompleted
ON : CPU No.3
preparation
completed
Turns on when an access to CPU No.3 from
another CPU becomes possible after power-
on or reset operation. This relay is used as an
interlock for accessing CPU No.3 when the
multiple CPU synchronous setting is set to
asynchronous.
SM223
CPU No.4
preparation
completed
OFF : CPU No.4
preparation
uncompleted
ON : CPU No.4
preparation
completed
Turns on when an access to CPU No.4 from
another CPU becomes possible after power-
on or reset operation. This relay is used as an
interlock for accessing CPU No.4 when the
multiple CPU synchronous setting is set to
asynchronous.
QnU
*5
SM235
Online module
change flag
OFF : Online module
change is not in
progress
ON : Online module
change in
progress
This relay is on during online module change.
(for host CPU)
S (During online
module change)
QnPH
SM236
Online module
change complete
flag
OFF : Online module
change
incomplete
ON : Online module
change complete
• This relay is on only for one scan after
completion of online module change.
• This relay can be used only in the scan
execution type program. (for host CPU)
S (When online
module change
is complete)
SM237
Device range
check
inhibit flag
OFF : Device range
checked
ON : Device range not
checked
Selects whether to check a device range
during execution of the BMOV, FMOV or
DFMOV instruction (only when the conditions
for subset processing are established).
U
QnU
*6
LCPU
