App-170
M9006 SM1006 - Battery low
OFF : Normal
ON : Battery low
• This relay turns on when the battery voltage
drops to or below the specified.
• It turns off when the battery voltage returns to
normal.
Qn(H)
QnPH
QnU
*1
LCPU
M9007 SM1007 - Battery low latch
OFF : Normal
ON : Battery low
• This relay turns on when the battery voltage
drops to or below the specified.
• This relay remains on even after the battery
voltage returns to normal.
M9008 SM1008 SM1
Self-diagnosis
error
OFF : No error
ON : Error
This relay turns on if an error is detected by self-
diagnostics.
M9009 SM1009 SM62
Annunciator
detection
OFF : No F number
detected
ON : F number
detected
• This relay turns on when the OUT F or SET F
instruction is executed.
• It turns off when the SD1124 value is cleared
to zero.
M9011 SM1011 SM56
Operation error
flag
OFF : No error
ON : Error
• This relay turns on when an operation error
occurs during execution of an application
instruction.
• This relay remains on even after the system
returns to normal.
Qn(H)
QnPH
QnU
*1
M9012 SM1012 SM700 Carry flag
OFF : Carry OFF
ON : Carry ON
Carry flag used in application instruction.
Qn(H)
QnPH
M9016 SM1016 ×
Data memory
clear flag
OFF : lgnored
ON : Output claered
When SM1016 turns on and remote RUN mode
is activated from a computer, all the data
memory including the latch range (except for the
special relay and special register) is cleared.
-
M9017 SM1017 ×
Data memory
clear flag
OFF : lgnored
ON : Output claered
When SM1017 turns on and remote RUN mode
is activated from a computer, all the data
memory that is not latched (except for the
special relay and special register) is cleared.
M9020 SM1020 -
User timing
clock No.0
• This relay repeatedly turns on and off at the
specified scan intervals.
• When the CPU module is powered on or
reset, this relay is set to on from off to start the
clock. Set the intervals of on/off by DUTY
instruction.
•n1: On scan interval
•n2: Off scan interval
When SM1020 to SM1024 are specified for
the DUTY instruction in programs, if the CPU
type is changed from the High Performance
model QCPU or Process CPU to the Universal
model QCPU or LCPU, they are replaced with
SM420 to SM424. (For the Universal model
QCPU and LCPU, SM1020 to SM1024 cannot
be specified.)
Qn(H)
QnPH
QnU
*1
LCPU
M9021 SM1021 -
User timing
clock No.1
M9022 SM1022 -
User timing
clock No.2
M9023 SM1023 -
User timing
clock No.3
M9024 SM1024 -
User timing
clock No.4
M9025 SM1025 -
Clock data set
request
OFF : Ignored
ON : Set request
present used
Clock data stored in SD1025 to SD1028 are
written to the CPU module after the END
instruction execution in the scan where SM1025
is turned on.
M9026 SM1026 - Clock data error
OFF : No error
ON : Error
This relay turns on if an error occurs in the clock
data (SD1025 to SD1028), and is off while there
is no error.
M9028 SM1028 -
Clock data read
request
OFF : Ignored
ON : Read request
This relay is turned on to read clock data and
store them as BCD values into SD1025 to
SD1028.
ACPU
Special
Relay
Special
Relay after
Conversion
Special
Relay for
Modification
Name Meaning Details
Corres-ponding
CPU
n1 scan
n2 scan n2 scan
DUTY n1 n2 SM1020
